P3C Technology Scales Perovskite Solar Modules As India’s IIT BHU Spinoff Targets Silicon’s Dominance

An IIT BHU spinoff is scaling up a new generation of solar modules built from perovskite crystals, a material scientists believe could eventually beat silicon on both efficiency and cost, as India races toward its renewable energy targets.

Highlights:

  • P3C Technology is a spinoff of IIT BHU Varanasi, with support from IIT Delhi
  • Its largest tested perovskite modules measure 30 sq cm at 15 percent efficiency
  • Standalone glass based perovskite cells have reached 20 percent power conversion efficiency
  • The company is scaling toward a 60 MW production capacity through 2025 and 2026
  • Modules are being validated by India’s National Institute of Solar Energy and sent to NREL in the US
  • P3C is also developing perovskite silicon tandem cells with a major Indian silicon manufacturer
Silicon has dominated the solar industry for so long that it is easy to forget the technology was never meant to be a permanent endpoint, simply the material that happened to be well understood and reliably manufacturable when the industry first scaled. P3C Technology and Solutions, a spinoff born out of IIT BHU Varanasi with additional support from IIT Delhi, is betting that a different material altogether, perovskite, a crystal structure first explored for solar applications back in 2009, may finally be ready to challenge silicon’s decades-long grip on the solar market. The company has spent the past several years quietly building the manufacturing capability to make that bet real rather than theoretical.
Understanding why perovskite has generated this much scientific and commercial interest requires understanding what actually makes it different from silicon at a material level. Perovskite refers not to a single substance but to any compound sharing a particular crystal structure, originally named after a naturally occurring calcium titanium oxide mineral. The hybrid halide perovskite solar cell represents what researchers classify as third-generation thin-film solar technology, following first-generation silicon wafers and a second generation of materials including gallium arsenide and cadmium telluride. Unlike silicon, which requires energy-intensive, high-temperature manufacturing processes, perovskite materials can be processed at considerably lower temperatures and deposited onto a genuinely wide range of substrates, including flexible surfaces that rigid silicon simply cannot accommodate. This opens the door to solar applications that traditional silicon panels were never physically capable of supporting, such as curved surfaces, vehicle exteriors, and building facades.
P3C’s own technical progress offers a useful, concrete window into how far this technology has actually come from laboratory curiosity toward commercial viability. Sooraj Kumar, the company’s CEO and co-founder and an alumnus of IIT BHU, stated that the company’s largest tested perovskite modules currently measure 30 square centimetres and achieve 15 percent efficiency, undergoing assessment through India’s National Institute of Solar Energy, the country’s dedicated autonomous body under the Ministry of New and Renewable Energy responsible for solar technology validation. Kumar noted plainly that the company has been working on perovskite solar cell technology for the past five years to reach this current module size, a timeline that underscores just how much sustained, incremental engineering work sits behind what might otherwise look like a sudden technology breakthrough. Separately, the company’s standalone glass-based perovskite cells have demonstrated 20 percent power conversion efficiency in what the company describes as uncontrolled, real-world testing conditions, a meaningfully different and generally more demanding benchmark than idealised laboratory measurements.
“P3C’s largest tested perovskite modules currently measure 30 square centimetres and achieve 15 percent efficiency.”
The company is not stopping at India’s own testing infrastructure either. P3C’s modules are currently in the process of being sent to the National Renewable Energy Laboratory in the United States, the US Department of Energy’s dedicated research facility and one of the most internationally respected independent validators of solar technology performance claims anywhere in the world. Securing NREL validation would represent a meaningful credibility milestone for P3C, particularly as the company looks to attract international partnerships and customers who may reasonably want independent, globally recognised verification before committing to a still-emerging solar technology at any meaningful scale.
Manufacturing scale, ultimately, will determine whether P3C’s technical achievements translate into genuine commercial relevance, and the company has laid out a fairly specific roadmap on this front. P3C has indigenously developed what it describes as a state-of-the-art production line integrating slot-die coating, a manufacturing technique well suited to perovskite’s lower-temperature processing requirements, and the company says this approach presents no inherent barrier to further capacity expansion. The scale-up plan targets 60 megawatts of production capacity across 2025 and 2026, working toward a considerably larger target module size of 90 centimetres by 180 centimetres, a dimension that would bring P3C’s modules much closer to the physical scale of commercially deployed solar panels rather than the smaller test-scale modules the company has validated so far. Kumar has separately indicated that P3C’s cost per watt is expected to approach and eventually surpass conventional silicon solar technology once the company’s production capacity reaches the 100-megawatt threshold, a benchmark that, if achieved, would represent the genuine commercial tipping point the entire perovskite solar industry has been working toward for years.
Beyond standalone perovskite modules, P3C has also been developing perovskite-silicon tandem cells in partnership with what the company describes as one of India’s largest silicon manufacturers, though the specific partner’s name has not yet been publicly disclosed. Tandem cells combine perovskite and conventional silicon layers within a single solar cell structure, a design approach that allows the combined cell to capture a considerably wider spectrum of sunlight than either material could capture on its own, since perovskite and silicon each respond most efficiently to different portions of the solar spectrum. This combination can meaningfully boost overall energy output per unit area compared to silicon alone, potentially lowering the total cost of energy production even before perovskite fully displaces silicon on its own, offering the industry a practical intermediate pathway toward higher-efficiency solar technology that does not require abandoning existing silicon manufacturing infrastructure entirely and immediately.
P3C has also moved beyond conventional rooftop and utility-scale solar applications into genuinely novel territory, reporting a project to integrate flexible perovskite modules directly onto Tata Motors’ Tata Ace electric commercial vehicle, an application that would have been physically impossible using rigid, heavy silicon panels. The company has developed two distinct product lines to serve different use cases: MySUN Glass, built on a rigid glass substrate suited to conventional rooftop and utility installations, and MySUN Flex, built on a flexible substrate designed specifically for curved surfaces, vehicles, and other applications where traditional rigid solar panels simply cannot be physically installed.
None of this progress should be read as evidence that perovskite solar technology’s path to commercial dominance is now assured or imminent, and it is worth resisting that temptation given the technology’s history. Perovskite materials have historically faced genuine durability and long-term stability challenges compared to silicon, which benefits from decades of proven, real-world performance data spanning multiple decades of continuous outdoor deployment, a track record perovskite technology simply cannot yet claim regardless of its promising laboratory and early field efficiency numbers. The independent reliability testing currently underway at India’s National Institute of Solar Energy, alongside the pending NREL validation, will matter enormously in determining whether P3C’s modules can genuinely withstand years of real-world sun, heat, humidity, and mechanical stress at the same level silicon panels have already proven they can reliably endure, a question that efficiency percentages alone cannot answer.
Viewed evenly, P3C’s progress represents a genuinely credible, methodically executed step within a solar technology category that carries real potential to reshape the economics of renewable energy generation globally, backed by concrete testing milestones, a specific and technically coherent manufacturing scale-up plan, and validation efforts spanning both Indian and internationally respected testing infrastructure. Whether perovskite genuinely displaces silicon as the dominant solar technology, or instead finds its most durable commercial footing as a complementary tandem technology layered on top of continued silicon manufacturing, remains a question that will likely take several more years of durability testing and manufacturing scale up to answer definitively, though P3C’s steady, verifiable progress toward that 100-megawatt cost parity threshold offers a genuinely useful, data-grounded signal that this is no longer purely a laboratory curiosity but a technology on a credible, if still unfinished, path toward commercial relevance.
